ดร.ฟิคสิท เพอร์มาซีล 1190
DR. Fixit Permaseal 1190
DR. Fixit Permaseal 1190ดร.ฟิคสิท เพอร์มาซีล 1190
ดร.ฟิคสิท เพอร์มาซีล 1190 เป็นยางหยอดร่องถนนคอนกรีต ชนิดพิเศษ ผลิตจากยางมะตอยผสมยางสังเคราะห์เรซินและสารเพิ่มคุณภาพอื่นๆ ทำให้มีคุณสมบัติดีเยี่ยม ในการป้องกันน้ำซึมลงรอยต่อถนนคอนกรีต อีกทั้งมีการยืดตัวสูงและสามารถยึดเกาะรอยต่อได้แน่น แม้ต้องแช่น้ำเป็นเวลานาน ๆ ดร.ฟิคสิท เพอร์มาซีล 1190 เป็นยางหยอดร่องในแนวระดับชนิดที่ต้องใช้ความร้อนเคี่ยวให้เหลว จนถึงจุดไหลเทที่ผลิตภัณฑ์สามารถยึดเกาะกับผิวคอนกรีตได้อย่างมีประสิทธิภาพ ดร.ฟิคสิท เพอร์มาซีล 1190 มีจุดไหลเทที่อุณหภูมิต่ำ อีกทั้งไม่มีส่วนผสมของน้ำมันที่ใช้เป็นสารละลาย จึงมีความปลอดภัยและประหยัดเวลาในการเคี่่ยว
ลักษณะการใช้งาน :
- หยอดร่องคอนกรีตทั่วๆไป เช่น
- ถนนคอนกรีต
- สะพาน
- เขื่อน
- รอยต่อพื้นแผ่นคอนกรีตทั่วไป ฯลฯ
วิธีการใช้งาน1. การเตรียมร่องหรือรอยต่อ:
- ร่องหรือรอยต่อต้องแห้งสะอาด ไม่มีเศษสิ่งสกปรกที่หลุดล่อนได้ง่าย ฝุ่นผง คราบน้ำมัน แว็กซ์ น้ำยาบ่ม คอนกรีด ผิวที่หลุดหรือรอยแตกบิ่ม ต้องทาการซ่อมด้วยวัสดุที่เหมาะสม เช่น ปูนซ่อมแซมโครงสร้างและทิ้งไว้ให้แห้ง ก่อนทางานในขั้นต่อไป
2. การทารองพื้น
- เพื่อการยึดเกาะที่ดีควรทาด้วยรองพื้น ดร.ฟิคสิท ไฟเมอร์ เจ ทิ้งไว้ให้แห้งก่อนทาการหยอดยาง
3. การทำงาน
- นำ ดร.ฟิคสิท เพอร์มาซีล 1190 ที่มีแผ่นพลาสติกหุ้มอยู่ (ไม่จำเป็นต้องแกะพลาสติกที่ห่อหุ้มออกเพราะพลาสติกจะละลายเป็นเนื้อเดียวกันกับผลิตภัณฑ์) ใส่ลงในหม้อหลอบที่มีน้ำมันเป็นตัวกลางส่งผ่านความร้อน
- ขณะหลอม ควรกวนให้เป็นเนื้อเดียวกัน ควมคุณ อุณหภูมิของน้ำมันไม่ให้เกิน 240 องศาเซลเซียสและ อุณหภูมิของยางหยอดร่องไม่เกิน 180 องศาเซลเซียส
- คนให้ยางละลายสม่ำเสมอ จนละลายหมด
- หยอด ดร.ฟิคสิท เพอร์ซีล 1190 ที่หลอมเป็นเนื้อเดียวกัน ลงในร่องคอนกรีด ควรใช้ให้หมดภายในเวลา 2-3 ชั่วโมง
- ทั้งไว้ให้แห้ง 4-5 ชั่วโมง ก่อนเปิดใช้งาน
4. การทำความสะอาด
- เครื่องมือที่ใช้ในการทำงาน ควรล้างทำความสะอาดด้วยน้ำมันก๊าด หรือน้ำมันสนทันทีที่ใช้งานเสร็จ
อายุและการเก็บรักษาผลิตภัณฑ์
- ไม่เกิน 1 ปี ในภาชนะที่ปิดสนิท เก็บในที่ร่มและแห้ง
ความปลอดภัยในการใช้งาน
- หากเกิดกรณีไฟลุกให้ใช้ผงเคมีแห้ง คาร์บอนไดออกไซด์ หรือทราย อย่าใช้น้ำดับไฟ
- อย่าให้ยางหยอดร่องที่ร้อนกระเด็นถูกผิวหนัง/ร่างกาย ในกรณีที่โดนยางขณะร้อน ให้ใช้น้ำเย็นราดบริเวณที่ โดยและรีบปรึกษาแพทย์ทันที
- อย่าให้น้ำหกลงไปในยางหยอดร่องที่ร้อน เพราะน้ำจะเดือดและยางหยอดร่องจะกระเด็นออกมา
*** ยางหยอดร่องคอนกรีต ชนิดเทร้อน ยืดตัวสูง
ขนาดบรรจุ |
: 15 กิโลกรัม
|
สี |
: สีดำ |
หมวดหมู่ |
: วัสดุยาแนวรอยต่อ |

DR. Fixit Permaseal 1190
Description :
Dr. Fixit Permaseal 1190 is a hot poured joint sealant. It is composed of special type of synthetic rubber, asphalt, resin, chemical additive and filler, it has excellent properties to prevent the passage of moisture down to the joint, high elasticity, adheres firmly and will not lose bond even if it is immersed in water for long time. Dr. Fixit Permaseal 1190 is for horizontal joint using heat to melt into liquid to pour temperature which will effectively bond to the concrete. Dr. Fixit Permaseal 1190 has low pour temperature containing no solvent making it highly save and saves melting time.
Area of Application :
- Seal horizontal joint of
- Concrete road.
- Bridge.
- Dam.
- Concrete floor joint of concrete slab etc.
Method of Application1. SURFACE PREPARTION
- The Joint must be clean, dry and free of dirt, dust or other loose materials.
2. PRIMING
- To ensure good adhesion of sealant, application of Dr.Fixit Primer J is recommended.
3. APPLICATION
- Melt Dr.Fixit Permaseal 1190 together with the wreapped plastic in oil-jackketed melter.
- Control temperature of heat transfer oil not higher than 240 °C and sealant not higher than 180 °C
- Stir sealant homogeneously until thoroughly melted.
- Pour melted sealant into prepared joints.
- The melted sealant should be used all in 2-3 hrs.
- Allow the poured sealant to dry and settle for 4-5 hrs before opening traffic.
4. CLEANING
- Tools and equipment should be cleaned immediately with kerosene or mineral turpentine.
Shelf Life & Storage
- Maximum 1 Year in sealed container kept under shed area
Health & Safety Precaution
- Incase of fire use dry chemical or carbondioxide or sand. Do not use water.
- If molten material comes onto contact with the skin, immerse the injured part under running cold water, and obtain medical advise immediately.
- Do not allow water to come into contaxt with molten material. This may cause it to boll over.
Other Product Categories available
- Waterproofing
- Repairing System
- Sealants
- Admixtures & Concrete Production
- Flooing
- Coating & Paints
- Tiling & Adhesive
- Grout & Anchors
*** A Hot - Applied Elastomeric Concrete Joint Sealant
PACKING |
: 15 kg.
|
COLOR |
: Black |
CATEGORY |
: Sealants |
